3A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF

  • 3A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF
  • 3A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF
  • 3A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF
Place of Origin CHINA
Brand Name THINKCHIP
Model Number RS3ABF
Minimum Order Quantity 100PCS
Price negotiable
Packaging Details Tape & Reel (TR) / Cut Tape (CT)
Delivery Time 1-2 WORK DAYS
Payment Terms T/T, Western Union,paypal, MoneyGram
Supply Ability 9,900,000 pcs/weekly

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
TYPE RS2ABF IFSM(A) 80A
VRRM(V) 50V Package SMBF
Trr(ns) 150 VF(V) 1.3
IR(uA) 5 IO(A) 3A
Highlight

high power rectifier diode

,

surface mount diode
Leave a Message
Product Description

RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF Fast Recorvery Diode SMBF 3A 50-1000V



other items

Type Io VRRM IFSM VF IR Trr Package
RS5MBF 5 1000 150 1.3 5 10 1000 500 SMBF
RS5KBF 5 800 150 1.3 5 10 800 500 SMBF
RS5JBF 5 600 150 1.3 5 10 600 250 SMBF
RS5GBF 5 400 150 1.3 5 10 400 150 SMBF
RS5DBF 5 200 150 1.3 5 10 200 150 SMBF
RS5BBF 5 100 150 1.3 5 10 100 150 SMBF
RS5ABF 5 50 150 1.3 5 10 50 150 SMBF
RS3MBF 3 1000 80 1.3 3 5 1000 500 SMBF
RS3KBF 3 800 80 1.3 3 5 800 500 SMBF
RS3JBF 3 600 80 1.3 3 5 600 250 SMBF
RS3GBF 3 400 80 1.3 3 5 400 150 SMBF
RS3DBF 3 200 80 1.3 3 5 200 150 SMBF
RS3BBF 3 100 80 1.3 3 5 100 150 SMBF
RS3ABF 3 50 80 1.3 3 5 50 150 SMBF
RS2MBF 2 1000 50 1.3 2 5 1000 500 SMBF
RS2KBF 2 800 50 1.3 2 5 800 500 SMBF
RS2JBF 2 600 50 1.3 2 5 600 250 SMBF
RS2GBF 2 400 50 1.3 2 5 400 150 SMBF
RS2DBF 2 200 50 1.3 2 5 200 150 SMBF
RS2BBF 2 100 50 1.3 2 5 100 150 SMBF
RS2ABF 2 50 50 1.3 2 5 50 150 SMBF
RS1MBF 1 1000 30 1.3 1 5 1000 500 SMBF
RS1KBF 1 800 30 1.3 1 5 800 500 SMBF
RS1JBF 1 600 30 1.3 1 5 600 250 SMBF
RS1GBF 1 400 30 1.3 1 5 400 150 SMBF
RS1DBF 1 200 30 1.3 1 5 200 150 SMBF
RS1BBF 1 100 30 1.3 1 5 100 150 SMBF
RS1ABF 1 50 30 1.3 1 5 50 150 SMBF



FEATURES
 Glass passivated junction
 Low reverse leakage current
 Low forward voltage drop
 Highcurrent capability
 Surface Mount device
MECHANICAL DATA
 Case: SMC(DO-214AB)
 Case Material: Molded Plastic. UL flammability
 Classification Rating: 94V-0
 Moisture Sensitivity: Level 1 per J-STD-020
 Weight: 0.21 grams (approximate)
3A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF 03A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF 13A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF 2

3A 50-1000V Fast Recovery Rectifier Diode RS3MBF RS3ABF RS3JBF RS3GBF RS3KBF RS3BBF RS3DBF SMBF 3
,
