FMS6141S5X Video IC Single Channel Voltage Regulator IC / 4th Order Video Filter Driver
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Part Status | Active | Type | Video Filter |
---|---|---|---|
Applications | DVD, HD, Set-Top Boxes, Recorders | Mounting Type | Surface Mount |
Package / Case | 5-TSSOP, SC-70-5, SOT-353 | Supplier Device Package | SC-70-5 |
High Light | three terminal voltage regulator,ldo voltage regulator |
Product Description
FMS6141 Low-Cost, Single-Channel 4th-Order Standard Definition Video Filter Driver
Manufacturer | ON Semiconductor |
Series | - |
Packaging | Tape & Reel (TR) |
Part Status | Active |
Type | Video Filter |
Applications | DVD, HD, Set-Top Boxes, Recorders |
Mounting Type | Surface Mount |
Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
Supplier Device Package | SC-70-5 |
Features
§Single 4th-Order 8 MHz (SD) Filter
Drives Single, AC- or DC-coupled, Video Loads
(2 Vpp, 150 Ω)
Drives Dual, AC- or DC-coupled, Video Loads (2Vpp,
75Ω)
Transparent Input Clamping
AC- or DC-Coupled Input
AC- or DC-Coupled Output
DC-Coupled Output Eliminates AC-Coupling
Capacitors
Single Supply
Robust 8 kV ESD Protection Lead-Free
Packages: SOIC-8 or SC70-5
Applications
Cable Set-Top Boxes
Satellite Set-Top Boxes
DVD Players
HDTVs
Personal Video Recorders (PVR)
Video On Demand (VOD)
