SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF

  • SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF
  • SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF
  • SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF
Place of Origin CHINA
Brand Name THINKCHIP
Model Number RS2ABF
Minimum Order Quantity 100PCS
Price negotiable
Packaging Details Tape & Reel (TR) / Cut Tape (CT)
Delivery Time 1-2 WORK DAYS
Payment Terms T/T, Western Union,paypal, MoneyGram
Supply Ability 9,900,000 pcs/weekly

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
TYPE RS2ABF IFSM(A) 50A
VRRM(V) 50V Package SMBF
Trr(ns) 150 VF(V) 1.3
IR(uA) 5 IO(A) 2A
High Light

fast recovery rectifier diode

,

surface mount diode
Leave a Message
Product Description

RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF Fast Recorvery Diode SMBF 2A 50-1000V


FEATURES
 Glass passivated junction
Low reverse leakage current
 Low forward voltage drop
 Highcurrent capability
 Surface Mount device
MECHANICAL DATA
 Case: SMB(DO-214AA)
 Case Material: Molded Plastic. UL flammability
 Classification Rating: 94V-0
 Moisture Sensitivity: Level 1 per J-STD-020
 Weight: 0.088 grams (approximate)



other items

Type Io VRRM IFSM VF IR Trr Package
RS5MBF 5 1000 150 1.3 5 10 1000 500 SMBF
RS5KBF 5 800 150 1.3 5 10 800 500 SMBF
RS5JBF 5 600 150 1.3 5 10 600 250 SMBF
RS5GBF 5 400 150 1.3 5 10 400 150 SMBF
RS5DBF 5 200 150 1.3 5 10 200 150 SMBF
RS5BBF 5 100 150 1.3 5 10 100 150 SMBF
RS5ABF 5 50 150 1.3 5 10 50 150 SMBF
RS3MBF 3 1000 80 1.3 3 5 1000 500 SMBF
RS3KBF 3 800 80 1.3 3 5 800 500 SMBF
RS3JBF 3 600 80 1.3 3 5 600 250 SMBF
RS3GBF 3 400 80 1.3 3 5 400 150 SMBF
RS3DBF 3 200 80 1.3 3 5 200 150 SMBF
RS3BBF 3 100 80 1.3 3 5 100 150 SMBF
RS3ABF 3 50 80 1.3 3 5 50 150 SMBF
RS2MBF 2 1000 50 1.3 2 5 1000 500 SMBF
RS2KBF 2 800 50 1.3 2 5 800 500 SMBF
RS2JBF 2 600 50 1.3 2 5 600 250 SMBF
RS2GBF 2 400 50 1.3 2 5 400 150 SMBF
RS2DBF 2 200 50 1.3 2 5 200 150 SMBF
RS2BBF 2 100 50 1.3 2 5 100 150 SMBF
RS2ABF 2 50 50 1.3 2 5 50 150 SMBF
RS1MBF 1 1000 30 1.3 1 5 1000 500 SMBF
RS1KBF 1 800 30 1.3 1 5 800 500 SMBF
RS1JBF 1 600 30 1.3 1 5 600 250 SMBF
RS1GBF 1 400 30 1.3 1 5 400 150 SMBF
RS1DBF 1 200 30 1.3 1 5 200 150 SMBF
RS1BBF 1 100 30 1.3 1 5 100 150 SMBF
RS1ABF 1 50 30 1.3 1 5 50 150 SMBF
SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF 0SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF 1SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF 2

SMBF 2A 50-1000V Fast Recovery Diode RS2MBF RS2ABF RS2JBF RS2GBF RS2KBF RS2BBFRS2DBF 3
,
