B320A B330A B340A B360A Schottky Diode Rectifier / SMD Sma Diode DIODES DO-214AC
| Place of Origin | CHINA |
|---|---|
| Brand Name | VISHAY/MIC/TOSHIBA/Thinkchip |
| Model Number | B320A B330A B340A B360A |
| Minimum Order Quantity | 100PCS |
| Price | negotiable |
| Packaging Details | Tape & Reel (TR) / Cut Tape (CT) |
| Delivery Time | 1-2 working days |
| Payment Terms | T/T, Western Union,paypal,MoneyGram |
| Supply Ability | 9,900,000 pcs |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| I(AV) | 0.53 | VRRM(V) | 20 |
|---|---|---|---|
| IF | 3A | IFSM(A) | 100 |
| IR | 500 | Package | SMA |
| TYPE | B320A B330A B340A B360A | ||
| High Light | diode schottky smd,high speed schottky diode |
||
Product Description
B320A B330A B340A B360A Schottky Diode SMD DIODES DO-214AC SMA
SCHOTTKY BARRIER DIODE FEATURES For use in low voltage, high frequency inverters Free wheeling, and polarity protection applications.
Contact us if you need more detail or quotation of these item. info@gr-ele.com
Pls kindly check the below part number of same series.
| B320A | 20 | 3 | 100 | 0.53 | 3 | 500 | - | SMA |
| B330A | 30 | 3 | 100 | 0.55 | 3 | 500 | - | SMA |
| B340A | 40 | 3 | 100 | 0.55 | 3 | 500 | - | SMA |
| B360A | 60 | 3 | 100 | 0.7 | 3 | 500 | - | SMA |
| Type | VRRM | I(AV) | IFSM | VF@IF | IR | Trr | Package | |
| SS12 | 20 | 1 | 30 | 0.55 | 1 | 500 | - | SMA |
| SS13 | 30 | 1 | 30 | 0.55 | 1 | 500 | - | SMA |
| SS14 | 40 | 1 | 30 | 0.55 | 1 | 500 | - | SMA |
| SS16 | 60 | 1 | 30 | 0.7 | 1 | 500 | - | SMA |
| SS18 | 80 | 1 | 30 | 0.85 | 1 | 500 | - | SMA |
| SS22 | 20 | 2 | 50 | 0.55 | 2 | 500 | - | SMA |
| SS23 | 30 | 2 | 50 | 0.55 | 2 | 500 | - | SMA |
| SS24 | 40 | 2 | 50 | 0.55 | 2 | 500 | - | SMA |
| SS26 | 60 | 2 | 50 | 0.7 | 2 | 500 | - | SMA |
| SS28 | 80 | 2 | 50 | 0.85 | 2 | 500 | - | SMA |
| SS32 | 20 | 3 | 100 | 0.55 | 3 | 500 | - | SMA |
| SS33 | 30 | 3 | 100 | 0.55 | 3 | 500 | - | SMA |
| SS36 | 60 | 3 | 100 | 0.7 | 3 | 500 | - | SMA |
| SS38 | 80 | 3 | 100 | 0.85 | 3 | 500 | - | SMA |
