MAX485CSA+ MAX485 SOP-8 5V Voltage Regulator IC

  • MAX485CSA+ MAX485 SOP-8 5V Voltage Regulator IC
  • MAX485CSA+ MAX485 SOP-8 5V Voltage Regulator IC
Place of Origin MALAYSIA
Brand Name MAXIM
Model Number MAX485CSA+
Minimum Order Quantity 100PCS
Price negotiable
Packaging Details Tape & Reel (TR) / Cut Tape (CT)
Delivery Time 1-2 working days
Payment Terms T/T, Western Union,paypal,MoneyGram
Supply Ability 9,900,000 pcs

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
TYPE MAX485CSA Package SOP8
REEL 2500/REEL DATE CODE NEW
Highlight

sop-8 power voltage regulator

,

2500/ reel ic voltage regulator
Leave a Message
Product Description

MAX485CSA+ MAX485 SOP-8 new original In Stock MAX485ESE MAXIM

Contact us if you need more detail or quotation of these item. info@gr-ele.com







Pls kindly check the below part number of same series.

General Description

The MAX481, MAX483, MAX485, MAX487–MAX491, and
MAX1487 are low-power transceivers for RS-485 and RS422
communication. Each part contains one driver and one
receiver. The MAX483, MAX487, MAX488, and MAX489
feature reduced slew-rate drivers that minimize EMI and
reduce reflections caused by improperly terminated cables,
thus allowing error-free data transmission up to 250kbps.
The driver slew rates of the MAX481, MAX485, MAX490,
MAX491, and MAX1487 are not limited, allowing them to
transmit up to 2.5Mbps.
These transceivers draw between 120µA and 500µA of
supply current when unloaded or fully loaded with disabled
drivers. Additionally, the MAX481, MAX483, and MAX487
have a low-current shutdown mode in which they consume
only 0.1µA. All parts operate from a single 5V supply.
Drivers are short-circuit current limited and are protected
against excessive power dissipation by thermal shutdown
circuitry that places the driver outputs into a high-impedance state.
The receiver input has a fail-safe feature that
guarantees a logic-high output if the input is open circuit.
The MAX487 and MAX1487 feature quarter-unit-load
receiver input impedance, allowing up to 128 MAX487/
MAX1487 transceivers on the bus. Full-duplex
communications are obtained using the MAX488–MAX491, while
the MAX481, MAX483, MAX485, MAX487, and MAX1487
are designed for half-duplex applications


MAX485CSA+ MAX485 SOP-8 5V Voltage Regulator IC 0MAX485CSA+ MAX485 SOP-8 5V Voltage Regulator IC 1

MAX485CSA+ MAX485 SOP-8 5V Voltage Regulator IC 2
