2K49 YAGEO 1206 SMD Resistor RC1206FR072K49 1206 1% 10R 1206 1R 1206 0R

  • 2K49 YAGEO 1206 SMD Resistor RC1206FR072K49 1206 1% 10R 1206 1R 1206 0R
Place of Origin china
Brand Name YAGEO
Model Number RC1206FR072K49
Minimum Order Quantity 100PCS
Price negotiable
Packaging Details Tape & Reel (TR) / Cut Tape (CT)
Delivery Time 1-2 working days
Payment Terms T/T, Western Union,paypal,MoneyGram
Supply Ability 9,900,000 pcs

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Size 1206 Resistance 2k49
Tolerance 1% Power (Watts) 0.25W, 1/4W
Temperature Coefficient ±100ppm/°C Operating Temperature -55°C ~ 155°C
High Light

yageo chip resistors

,

0805 smd resistor
Leave a Message
Product Description

2K49 YAGEO 1206 SMD Resistor RC1206FR072K49 1206 1% 10R 1206 1R 1206 0R






G-Resource Ele. people firmly believe that adhere to expand the "people-oriented" concept of corporate culture, with the core technology innovation, a good industrial base and a leading position in the market,becoming world-class semiconductor leading enterprises.
Looking forward to the future, G-Resource Ele.will be based on China, and Looking at the world, to create the international famous brand and to be leader of China′s excellent semiconductor.



RC1206FR072K49

1206 1% 2K49

Chip resistor YAGEO resistor 1206 10R 1206 1R 1206 0R

The resistor is constructed on top of a high-grade ceramic body. Internal metal electrodes are added on each end to make the contacts to the thick film resistive element. The composition of the resistive element is a noble metal imbedded into a glass and covered by a second glass to prevent environmental influences. The resistor is laser trimmed to the rated resistance value. The resistor is covered with a protective epoxy coat, finally the two external terminations (matte tin on Ni-barrier) are added, as shown in Fig.6.



RC0075 0.30±0.01 0.15±0.01 0.10±0.01 0.08±0.03 0.08±0.03
RC0100 0.40±0.02 0.20±0.02 0.13±0.02 0.10±0.03 0.10±0.03
RC0201 0.60±0.03 0.30±0.03 0.23±0.03 0.10±0.05 0.15±0.05
RC0402 1.00±0.05 0.50±0.05 0.35±0.05 0.20±0.10 0.25±0.10
RC0603 1.60±0.10 0.80±0.10 0.45±0.10 0.25±0.15 0.25±0.15
RC0805 2.00±0.10 1.25±0.10 0.50±0.10 0.35±0.20 0.35±0.20
RC1206 3.10±0.10 1.60±0.10 0.55±0.10 0.45±0.20 0.40±0.20
RC1210 3.10±0.10 2.60±0.15 0.55±0.10 0.45±0.15 0.50±0.20
RC1218 3.10±0.10 4.60±0.10 0.55±0.10 0.45±0.20 0.40±0.20
RC2010 5.00±0.10 2.50±0.15 0.55±0.10 0.45±0.15 0.50±0.20
RC2512 6.35±0.10 3.10±0.15 0.55±0.10 0.60±0.20 0.50±0.20







YAGEO full series chip resistor stock

if you need pls contact with us, Tks
